Registers
- 40 -
Modbus RS485 Interface
Operating Guide
Registers
Dissolved Oxygen Configuration Continued
4675 Get/Set Channel 1 Pressure
Damping Limit
B*
FLOAT Pressure Damping Limit
B Value
*(Only available when
pressure damping set to
enable)
Atm: 0 to 99.99
5265 Channel 2 Bar: 0 to 99.99
5865 Channel 3 Kpa: 0 to 9999
mH20: 0 to 999.9
Psi: 0 to 999.9
mmHg: 0 to 9999
4677 Get/Set Channel 1 Input Pressure* FLOAT Fixed Input Pressure
Value
*(Only available when
pressure compensation
mode set to manual)
Atm: 0 to 99.99
5267 Channel 2 Bar: 0 to 99.99
5867 Channel 3 Kpa: 0 to 9999
mH20: 0 to 999.9
Psi: 0 to 999.9
mmHg: 0 to 9999
4679 Get/Set Channel 1 Input Filter INT Dissolved Oxygen Input
Filter
1050 = Filter Out
5269 Channel 2 1051 = 10 Seconds
5869 Channel 3 1052 = 20 Seconds
1053 = 40 Seconds
1054 = 1 Minutes
1055 = 3 Minutes
1056 = 5 Minutes
