Registers
- 42 -
Modbus RS485 Interface
Operating Guide
Registers
Electrodeless Conductivity Configuration Continued
4740 Get/Set Channel 1 Custom Curve 1
Third Units
INT 3
rd
Character of Custom
Curve 1 Units
Refer To Table 1
5330 Channel 2
5930 Channel 3
4741 Get/Set Channel 1 Custom Curve 1
Fourth Units
INT 4
th
Character of Custom
Curve 1 Units
5331 Channel 2
5931 Channel 3
4742 Get/Set Channel 1 Custom Curve 1
Fifth Units
INT 5
th
Character of Custom
Curve 1 Units
5332 Channel 2
5932 Channel 3
4743 Get Channel 1 Custom Curve 1
Sixth Units
INT 6
th
Character of Custom
Curve 1 Units
5333 Channel 2
5933 Channel 3
4744 Get/Set Channel 1 Custom Curve 1
Solution Range
INT Custom Solution Curve
1 Solution Operating
Range
1567 = 0-9.999
5334 Channel 2 1568 = 0-99.99
5934 Channel 3 1569 = 0-999.9
1570 = 0-9999
4745 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 1
FLOAT Custom Curve 1
Conductivity Point 1
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5335 Channel 2
5935 Channel 3
4747 Get/Set Channel 1 Custom Curve 1
Solution Point 1
FLOAT Electrodeless Custom
Input 1 Solution Point 1
Value
Value Dependant on
Custom Curve 1 Solution
Range
5337 Channel 2
5937 Channel 3
4749 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 2
FLOAT Custom Curve 1
Conductivity Point 2
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5339 Channel 2
5939 Channel 3
4751 Get/Set Channel 1 Custom Curve 1
Solution Point 2
FLOAT Electrodeless Custom
Curve 1 Solution Point 2
Value
Value Dependant on
Custom Curve 1 Solution
Range
5341 Channel 2
5941 Channel 3
4753 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 3
FLOAT Custom Curve 1
Conductivity Point 3
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5343 Channel 2
5943 Channel 3
4755 Get/Set Channel 1 Custom Curve 1
Solution Point 3
FLOAT Electrodeless Custom
Curve 1 Solution Point 3
Value
Value Dependant on
Custom Curve 1 Solution
Range
5345 Channel 2
5945 Channel 3
4757 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 4
FLOAT Custom Curve 1
Conductivity Point 4
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5347 Channel 2
5947 Channel 3
4759 Get/Set Channel 1 Custom Curve 1
Solution Point 4
FLOAT Electrodeless Custom
Curve 1 Solution Point 4
Value
Value Dependant on
Custom Curve 1 Solution
Range
5349 Channel 2
5949 Channel 3
4761 Get/Set Channel 1 Custom Curve 1
Conductivity
Point 5
FLOAT Custom Curve 1
Conductivity Point 5
Value
Value Dependant on
Custom Curve 1
Conductivity Range
5351 Channel 2
5951 Channel 3
4763 Get/Set Channel 1 Custom Curve 1
Solution Point 5
FLOAT Electrodeless Custom
Curve 1 Solution Point 5
Value
Value Dependant on
Custom Curve 1 Solution
Range
5353 Channel 2
5953 Channel 3
