ZOOM
OFF
OFF
100
DE TH RANGE P
AUTO 1 0 0
AUTO
6.3 Depth Range---
Press the POWER - MENU key until DEPTH RANGE
appears. Automatic is the default setting. When in
automatic, the lower range will be adjusted by the unit to
follow the bottom. (Auto, 1-100)
NOTE: In manual operation, if the depth is greater than
the depth range settings, the bottom will not be visible on
the display. Select AUTO to return to automatic operation.
6.4 Zoom---
Press the POWER - MENU key until ZOOM appears.
Select Auto to magnify the area around the bottom in
order to reveal fish and structure close to the bottom that
may not be visible during normal operation. When ZOOM
is set to Auto, the upper and lower Depth Ranges are
automatically adjusted to keep the area above and below
the bottom on the display. Select Off to return to normal
operation. (Off, Auto, 1-100).
the display may not show many sonar returns that could
be fish. (1 –9).
-7-
