17 Operating manual – multifunction measuring meter XA1000 / XP200 / XP400 • 08_2015 GB
"Measuring mode – Humidity – Automatic measurement" screen
78 Displays the measured values according to the
specifications under 70 and 75 in fig. A.:
°C: Displays the temperature according to the
specifications under 70 (e.g. in degrees
Celsius) and under 75 (e.g. as average value):
g/m
3
:
Displays the humidity according to the
specifications under 70 (e.g. in gram per cubic
metre) and under 75 (e.g. as average value):
mmHg: Displays the air pressure according to the
specifications under 70 (e.g. in the measuring
unit millimetres of mercury) and under 75 (e.g.
as average value):
79 Indicates the remaining recording duration for the automatic
measurement.
80 Opens a screen for selecting the recording duration for
measuring over a long period (see fig. D.).
81 Starts recording.
The key turns red once recording has started.
Note!
During an active recording it is not possible to switch off the
multifunction measuring meter with the "On/Off" key.
Automatic switch-off is also deactivated. First stop the
recording by pressing key 82 and then turn off the device.
82 Stops the current recording. The detected values are
automatically saved to the current measuring project.
83 Pauses the current recording.
Key 81 flashes.
Press this key again to continue recording.
