GB Operating manual – multifunction measuring meter XA1000 / XP200 / XP400 • 08_2015 16
"Measuring mode – Humidity" screen
70 Specifies how measured values and the corresponding units
are shown (see chapter "Explanation of the measured values",
page 19). The latest measured value is displayed next to the
corresponding key on the right.
Select "Off" to switch the respective display off.
71 This symbol indicates that the displayed measured values
under 73 are calculated (e.g. minimum/maximum measured
value).
72 Indicates the measurement duration.
73 Displays the measured values according to the
specifications under 70 and 75:
°C: Displays the temperature according to the
specifications under 70 (e.g. in degrees
Celsius) and under 75 (e.g. as average value):
g/m
3
:
Displays the humidity according to the
specifications under 70 (e.g. in gram per cubic
metre) and under 75 (e.g. as average value):
mmHg: Displays the air pressure according to the
specifications under 70 (e.g. in the measuring
unit millimetres of mercury) and under 75 (e.g.
as average value):
74 Sets the measured values shown under 73 back to zero.
75 Specifies how the measured values under 73 are shown
(see fig. B.):
Minimum: Always shows the smallest detected measured
value from a measuring period.
Maximum: Always shows the largest detected measured
value from a measuring period.
Average: Shows the average value of all detected
measured values from a measuring period.
Hold: Holds the current detected measured value and
shows it continually (when this option is
selected).
Off: Switches off the measured values indication
under 73.
76 Carries out an automatic measurement for the duration of a
predefined recording interval. The recording interval can be
specified in the following screen (see fig. C. and fig. D.,
page 17).
77 Saves the currently displayed measured value as single
measurement in the archive with date and time stamp.
