21 Operating manual – multifunction measuring meter XA1000 / XP200 / XP400 • 08_2015 GB
"Archive" screen
In the "Archive" screen, you can view archived
measuring projects or open them for further
processing:
Archive, fig. A.:
The icons beside the saved measuring projects show
each measuring mode (see examples in fig.A.). The
meaning is as follows:
84 Shows the measuring projects which are saved in the archive.
The currently selected archive entry is highlighted.
Navigate in the archive as follows:
1. Press the "Down" key on the cross control until the desired
archive entry is selected.
2. You may need to turn the page by pressing the "Left" or
"Right" keys on the cross control.
3. Press the "OK" key on the cross control to confirm the
selected archive entry. You can also press "OK" (85) on the
screen. Fig. B., page 22 opens.
85 Selects the currently selected archive entry. Fig. B.,
page 22 opens.
86 Deletes all entries from the archive. A safety prompt opens.
Confirm it by pressing the "OK" key if you want to delete all
entries. Otherwise, touch the "Cancel" key.
Flowrate measurement
Measurement of humidity, temperature or air pressure
Spot measurement
Time measurement
