Lumantek ez-HSV+ User Manual

Data Input
Analog Audio Input: Stereo Jack x1
HDMI Video Input : SD/ HD/ 3G (HDMI Type A) x 1
Video Formats:
- 720x480i@59.94/60
- 720x576i@50
- 1280x720p@50/59.94/60
- 1920x1080i@50/59.94/60
- 1920x1080p@23.94/24/25/29.97/30
- 1920x1080p@50/59.94/60
Data Output
SDI Video Output: SD/HD/3G-SDI (BNC 75Ω) x1
Video Formats:
- 720x480i@59.94 (DIP SW : 1111)
- 720x576i@50 (DIP SW : 0111)
- 1280x720p@50 (DIP SW : 1011)
- 1280x720p@59.94 (DIP SW : 0011)
- 1280x720p@60 (DIP SW : 1101)
- 1920x1080i@50 (DIP SW : 0101)
- 1920x1080i@59.94 (DIP SW : 1001)
- 1920x1080i@60 (DIP SW : 0001)
- 1920x1080p@23.98 (DIP SW : 1110)
- 1920x1080p@24 (DIP SW : 0110)
- 1920x1080p@25 (DIP SW : 1010)
- 1920x1080p@29.97 (DIP SW : 0010)
- 1920x1080p@30 (DIP SW : 1100)
- 1920x1080p@50 (DIP SW : 0100)
- 1920x1080p@59.94 (DIP SW : 1000)
- 1920x1080p@60 (DIP SW : 0000)
Connections
Power : DC Power Input (DC Jack) x1
DIP Switch : (6 Pole) x1 Video In/Out Resolution,
Video Output Ratio, Audio(INT. or EXT.)
MODE : (Push Switch) x1 LCD ON/OFF, Menu
Selection
Display
2.7 inch TFT LCD : Input Video
Display, In/Output Video
Resolution Display,
Input Audio Level Meter Display
Electrical
Power Input: DC +5V to +18V
Power Consumption: 4W(max.)
Operation Temperature: 0~45℃
Physical
Dimension: 86.3x57.2x26.6 (include
connector)
Weight: 0.66lbs (0.3 kg)(typ.)
04. Technical Specification

Lumantek ez-HSV+ Specifications

Video Input

analog audio input	Stereo Jack x1
hdmi video input	SD/ HD/ 3G (HDMI Type A) x 1
video formats	720x480i@59.94/60, 720x576i@50, 1280x720p@50/59.94/60, 1920x1080i@50/59.94/60, 1920x1080p@23.94/24/25/29.97/30, 1920x1080p@50/59.94/60

Video Output

sdi video output	SD/HD/3G-SDI (BNC 75Ω) x1
video formats	720x480i@59.94, 720x576i@50, 1280x720p@50, 1280x720p@59.94, 1280x720p@60, 1920x1080i@50, 1920x1080i@59.94, 1920x1080i@60, 1920x1080p@23.98, 1920x1080p@24, 1920x1080p@25, 1920x1080p@29.97, 1920x1080p@30, 1920x1080p@50, 1920x1080p@59.94, 1920x1080p@60

Connections

power connection	DC Power Input (DC Jack) x1
dip switch	(6 Pole) x1 Video In/Out Resolution, Video Output Ratio, Audio(INT. or EXT.)
mode switch	(Push Switch) x1 LCD ON/OFF, Menu Selection

Display

display type	2.7 inch TFT LCD
display features	Input Video Display, In/Output Video Resolution Display, Input Audio Level Meter Display

Electrical

power input	DC +5V to +18V
power consumption	4W(max.)
operation temperature	0~45℃

Physical Characteristics

dimensions	86.3x57.2x26.6 (include connector)
weight	0.66lbs (0.3 kg)(typ.)
