IS 310 / IGA 310 Manual Introduction
•
9
2 Introduction
2.1 Appropriate use
The IS 310 and IGA 310 are stationary pyrometers for non-contact temperature measurement of
metallic surfaces, graphite, ceramics, etc.
2.2 Scope of delivery
Instrument, works certificate, and user manual.
Note: A connection cable is not included with the instrument and has to be ordered
separately (see Chapter 7, Reference numbers).
2.3 Technical data
Temperature Ranges:
IS 310
IGA 310
650 ... 1800 °C (MB 18)
800 ... 2300 °C (MB 23)
1100 ... 2500 °C (MB 25)
300 ... 1300 °C (MB 13L)
500 ... 1500 °C (MB 15)
Spectral Range:
IS 310
0.8 ... 1.1 µm (Si photo detector)
IGA 310
1.45 ... 1.8 µm (InGaAs photo detector)
Power Supply:
24 V DC ± 25% stabilized, ripple < 50mV
5 ... 30 V DC for LED targeting light (I ≤ 30 mA)
Output:
4 ... 20 mA load independent current, linear to temperature
Max load: Max. 500 Ω at 24 V
Max. 200 Ω at 18 V
Max. 800 Ω at 30 V
Emissivity:
0.2 ... 1; Adjustable
Accuracy:
(ε = 1, T
amb.
= 23 °C)
Up to 1500 °C: 0.8% of measured value + 1 °C
Above 1500 °C: 1% of measured value + 1 °C
Repeatability:
(ε = 1, T
amb.
= 23 °C)
0.3% of measured value
Response Time t
90
:
10 ms
Sighting:
LED targeting light
Housing:
Stainless Steel
Weight:
215 g
Ambient Temperature:
0 ... 70 °C
Storage Temperature:
-20 ... 70 °C
Mounting Position:
Any
Protection Class:
IP65 (DIN 40050)
Connection Cable:
2 m - 30 m, with connector
CE label:
According to EU-directives about electromagnetic immunity
