46233
46235
46237
46239
46241
46243
46245
46247
46249
46251
46253
46255
46265
Datalog Parameter 21
Datalog Parameter 22
Datalog Parameter 23
Datalog Parameter 24
Datalog Parameter 25
Datalog Parameter 26
Datalog Parameter 27
Datalog Parameter 28
Datalog Parameter 29
Datalog Parameter 30
Load Profile Datalog Select
Start Date of Load Profile Datalog
Old Parameters Enable disable
18
18
18
18
18
18
18
18
18
18
18
18
18
116
117
118
119
120
121
122
123
124
125
126
127
132
58
5A
5C
5E
60
62
64
66
68
6A
6C
6E
78
Address
(Register)
Param-
eter No.
Parameter
Read/
Write
Modbus Start Addr. Hex
High Byte
Low Byte
Default
Value
TABLE 3 : continued...
R/Wp
R/Wp
R/Wp
R/Wp
R/Wp
R/Wp
R/Wp
R/Wp
R/Wp
R/Wp
R/Wp
R
R/Wp
0
0
0
0
0
0
0
0
0
0
0
0
0
NOTE: Wp - Write protected , R - Read only , R/Wp - Read & Write protected
This address is used to set the System type.
Write one of the following value to this address.
1: 1 Phase 2 Wire
2: 3 Phase 3 Wire
3: 3 Phase 4 Wire.
Address Parameter Description
46003
Demand
Integration Time
Demand period represents demand time in minutes. The applicable values are
8,15,20 or 30.
46007
System Voltage
This address is read only and displays System Nominal Voltage
46009
System Current This address is read only and displays System Nominal Current
46011
System Type
Explanation for 4 X register :
This address is used to set energy output in Wh,kWh & MWh.
Write one of the following value to this address.
1: Energy in Wh. 2: Energy in KWh.
3: Energy in MWh.
Energy Output
46005
NOTE: Writing any invalid values (non-applicable values) to any of the following locations will result in modbus error.
25
