Address Parameter Description
46013
Pulse Width
of Relay
This address is used to set pulse width of the Pulse output.
Write one of the following values to this address:
60 : 60 ms
100 : 100 ms
200 : 200 ms
46015
Reset
Parameters
This address is used to reset different parameters. Write specific value to this
register to reset the corresponding parameter. Following are the values to reset
various data.
1: Energy Reset 2: Demand Reset
3: System Min Values Reset 4: System Max Values Reset
5: Run hour & On hour Reset 6: No of Interruptions Reset
7: Reset All data 8: Time Datalog
9: Load Profile Datalog
46017
Number of Poles This address is used to set the no. of poles of generator of which RPM
is to be measured. The value must be between 2 to 40 and a multiple of 2.
46019
Rs485 Set-up
Code
This address is used to set the baud rate, Parity and Number of stop bits.
Refer to TABLE 4 for details.
46021
Node Address
This register address is used to set Device address between 1 and 247 .
This address allows the user to set CT Primary value.
The settable range is 1 to 9999. It also depends on the per phase
1000 MVA Restriction of power combined with PT primary.
46035
CT Pimary
46033
PT Primary This address allows the user to set PT Primary value (in terms of VL-L).
The settable range is 100 VL-L to 1200 kVL-L for all system types & also
depends on the per phase 1000 MVA Restriction of power combined with
CT primary.
46023
Pulse Divisor
This address is used to set pulse divisor of the Pulse output.
Write one of the following values to this address for Wh:
1 : Divisor 1
10 : Divisor 10
100 : Divisor 100
1000 : Divisor 1000 & In kWh or MWh divisor will be 1 default.
46037
Sys Power System Power (Read Only) is the Nominal system power based on the values
of Nominal system volts and Nominal system current.
26
