4. Datalogging
Datalogging is a feature that allows the meter to store measured parameters based on time or on occurrence of a
certain event. The user can retrieve the data later for further application.
This meter offers three types of datalogging
1) Event based 2) Time based 3) Load profile
4.1 Event Based Datalogging
This type of datalogging stores data when certain event is observed. This data is time stamped and last five
occurrences of each type of event are stored based on first in first out queue. This meter offers event based logging
for 10 parameters. This data can be observed on the modbus on the address table shown below. These registers
can be accessed by the query explained in section 3.1 The user can turn this logging on and off through display as
well as modbus by using address 46185.
Changing any setup parameter related to the logged parameters will reset the log.
Note: Below addresses are available for 3X and for 4X.
for example 312289 for 3X and 412289 for 4X.
312289
Max Voltage
Date 1 30 00
312291 Time 1 30 02
312293 Value 1 30 04
312295 Date 2 30 06
312297 Time 2 30 08
312299 Value 2 30 0A
312301 Date 3 30 0C
312303 Time 3 30 0E
312305 Value 3 30 10
312307 Date 4 30 12
312309 Time 4 30 14
312311 Value 4 30 16
312313 Date 5 30 18
312315 Time 5 30 1A
312317 Value 5 30 1C
312319
Min Voltage
Date 1 30 1E
312321 Time 1 30 20
312323 Value 1 30 22
312325 Date 2 30 24
312327 Time 2 30 26
312329 Value 2 30 28
312331 Date 3 30 2A
312333 Time 3 30 2C
312335 Value 3 30 2E
312337 Date 4 30 30
312339 Time 4 30 32
312341 Value 4 30 34
312343 Date 5 30 36
312345 Time 5 30 38
312347 Value 5 30 3A
Address
Logged
Parameter
Log
Details
Mod Start Address Hex
High Byte Low Byte
Address
Logged
Parameter
Log
Details
Mod Start Address Hex
High Byte Low Byte
Table 16: Addresses for event based datalog
47
