Lumel ND25 User Manual

46041
Word Order
Word Order controls the order in which Multifunction Meter receives or sends
floating - point numbers:- normal or reversed register order . In normal mode, the
two registers that make up a floating point numbers are sent most significant bytes
first. In reversed register mode , the two registers that make up a floating point
numbers are sent least significant bytes first. To set the mode, write the value ‘
2141.0’ into this register-the instrument will detect the order used to send this value
and set that order for all ModBus transaction involving floating point numbers.
46045
PT secondary This address is used to read and write the PT secondary value.
The settable range is 100-600VLL.
46043
CT secondary
This address is used to read and write the CT secondary value. Write one of the
following values to this address.
1: 1A CT secondary
5: 5A CT secondary
This address is used to set Energy Digit Reset Count value. Energy count can be
configured to reset in between 7 to 9.
Energy Digit
Reset Count
46039
46047 Relay 1 output
select
This address is used to select the Relay operation as Pulse/Timer/RTC Relay/Limit.
Write one of the following values to this address.
0: Pulse output on Relay
10 (Decimal): Timer mode for Relay
40 (Decimal): RTC mode for Relay.
128 (Decimal): Limit output on Relay.
46049
Relay 1 Para
select/ No. of
Cycles/ Weekly
repeat
46051
Limit 1
Trip Point
46053
Limit 1
Hysteresis
This address is used to assign the Parameter to Relay.
Pulse relay: Refer TABLE 5
Timer relay: Refer TABLE 6
RTC relay: Refer TABLE 7
Limit relay: Refer TABLE 8
This address is used to set the trip point in %. Any value between 10 to 100 for
Lo- alarm & 10 to120 for Hi-alarm can be written to this address. For energy
parameters, the valid range id 10-9999999. (refer TABLE 8).
This address is used to set the hysteresis between 0.5 to 50.0%.
This address is used to set the Energizing delay or On delay in seconds in range
of 1 to 9999. For RTC Relay this range is 00.00 to 23.59.
46055
Relay 1 On
(Energize) Delay/
On Time
Address Parameter Description
27
