Lumel ND25 User Manual

46061
46071
Password
This address is used to set & reset the password.
Valid Range of Password can be set is 0000 - 9999 .
1) If password lock is present & if this location is read it will return zero.
2) If Password lock is absent & if this location is read it will return One.
3) If password lock is present & to disable this lock first send valid password to
this location then write “0000” to this location
4) If password lock is present & to modify 4X parameter first send valid
password to this location so that 4X parameter will be accessible for
modification.
5) If for in any of the above case invalid password is send then meter will return
exceptional error 2.
46059
46063
46065
46069
46067
Relay 2 output
select
Limit 2
Trip Point
Limit 2
Hysteresis
Relay 2 On
(Energize) Delay/
On Time
Relay 2 Off (De-
Energize) Delay/
Off Time
Relay 2 Para
select/ No. of
Cycles/ Weekly
repeat
Same as Relay 1.
46075
Limit 2 Configu-
ration Select
This address is used to set the Configuration for Relay 1
Refer TABLE 9.
Relay 1 Configu-
ration Select
46073
This address is used to set the Configuration for Relay 2
Refer TABLE 9.
46057
This address is used to set the De-energizing delay or Off delay in seconds in
range of 1 to 9999. For RTC Relay this range is 00.00 to 23.59.
Relay 1 Off (De-
Energize) Delay/
Off Time
Address Parameter Description
28
