46081 Energy Update
Rate
This address is used to specify update rate of energy in corresponding
3X registers. The valid values for update rate are from 1 to 60 min.
46083 Factory Reset
This address allows the user to reset the instrument to factory settings. Refer
the Default Values in TABLE 3 for factory settings. Write 5555 at this address to
reset the instrument.
46087
System
Frequency
Selection
46089
Impulse
Selection
This address is used to select the energy to which impulse is to be assigned.
Writing any other value will return an error.
0: None 1: Active Energy
2: Reactive Energy 3: Apparent Energy
This address is used to set the frequency of the input.
Write 50: For 50 Hz input 60: For 60Hz input
46091
Energy
Parameter
Selection
46093
Energy
Start
Count
46095
Timer 1
Start/ Stop
46097
Timer 2
Start/ Stop
This address is used to start/stop the timer for Relay 1 in timer mode with following
options: 0: Stop 1: Start
This address is used to start/stop the timer for Relay 2 in timer mode with following
options: 0: Stop 1: Start
This address is used to select the parameter whose start count (initial value) is
to be set. Refer TABLE 10.
This address is used to set the start count of the parameter selected in address
46091. The start count of the parameter should be in the range specified in
TABLE 10.
This address is used to activate or de-activate the auto scrolling.
Write 0: Deactivate 1: Activate
46077
Auto scroll
46079
30mA Noise
current
Elimination
This address is used to activate or de-activate the 30 mA noise current
elimination write
0: Deactivate 30 (Decimal): Activate
Address Parameter Description
29
