Code Configuration
0 Hi - alarm & energised Relay
1 Hi - alarm & De-energised Relay
2 Lo - alarm & Energised Relay
3 Lo - alarm & De-energised Relay
For Limit Relay
For Timer or RTC relay
Code Configuration
0 Energize when triggered
1 De-energize when triggered
TABLE 9: Relay Configuration
Parameter
Number
Parameter Range
1
2
3
4
5
7
8
9
10
11
Imp Active Energy Start Count
Exp Active Energy Start Count
Capacitive Reactive Energy Start Count
Inductive Reactive Energy Start Count
Apparent Energy Start Count
Imp Active Energy Overflow Start Count
Exp Active Energy Overflow Start Count
Capacitive Reactive Energy Overflow Start Count
Inductive Reactive Energy Overflow Start Count
Apparant Energy Overflow Start Count
0 to 999999999
0 to 999999999
0 to 999999999
0 to 999999999
0 to 999999999
0 to 999999
0 to 999999
0 to 999999
0 to 999999
0 to 999999
TABLE 10: Energy Parameter Selection and Start Count
