14
5. EXECUTION CODES
Execution codes of the P20 transducer
Table 2.
TRANSDUCER P20 - X X XX XX X
Analog outputs:
current 0... 20 mA ...................... 1
current 4... 20 mA ...................... 2
voltage 0... 10 V ........................ 3
Supply:
85...253 V a.c./d.c. ............................1
20 … 85 V d.c., 20...65 V a.c. ...........2
Kind of input
see table 3 ............................................... XX
Execution:
standard .......................................................... 00
custom-made* .................................................XX
Acceptance tests:
without extra quality requirements ........................... 8
................ 7
with test certificate .................................................... 4
acc. to customer’s requirements* ............................. X
* after agreeing with the manufacturer
EN
