When setting the SPECTRA or SPECTRA X up for use, be sure to place the unit on a hard surface
and avoid blocking or restricting airflow at the air intake (front panel, left of the light output port) or
exhaust ports (on the underside of the unit, see Figure 9). The unit must be operated in a non-
condensing environment (dew point <10ºC with controlled ambient temperature <30º C). Restricting
the airflow will cause the unit to operate at elevated temperatures and will result in decreased
product life and/or premature failure. Position the unit in such an orientation that allows unrestricted
access to the DC power connector. In an emergency, you may need to disconnect power to the unit
quickly.#
To install the output adapter, remove the
shipping cover from the light output port on the
front panel by extracting the four M4 fixing
screws. Insert the output adapter (Figure 2) into
the output port and secure it with an M4 fixing
screw in each corner. Retain the light output
port shipping cover and re-install it in the event
that the light engine requires transportation. #
