5. Product Specifications
SPECTRA and SPECTRA X light engines must be operated and stored within the environmental
conditions specified below. Performance specifications for individual light engines are listed on the
certificate of conformance included with the shipping documents e-mailed to the customer (Figure
1). It is important to retain the certificate of conformance for reference. In the event that the light
engine is sold or transferred, the certificate of conformance should be conveyed to the new owner.
Certificates of conformance are also recorded in Lumencor’s database and copies can be requested
by e-mail to techsupport@lumencor.com. The request message must include the 4- or 5- digit serial
number of the light engine.#
Specification
Detail
Temperature
Operating
32 to 95° F (0 to 35° C)
Non-operating
-4 to 158° F (-20 to 70° C)
Humidity
Operating and non-operating
0 to 80% relative humidity, non-condensing
SPECTRA and SPECTRA X Light Engine Manual 57-10006! ! ! 17
Figure 8. Representative spectral output of a SPECTRA X light engine equipped with bandpass filters
compatible with Chroma Technology quad band dichroic VCGR-SPX-P01-PC and emitter VCGR-SPX-P01-
EM. All outputs are electronically selectable except for Green/Yellow, which is accomplished by manual
interchange of filters.
