Step 3 - connection
For CAT6 cable entry to e
2
device
the slit, as per image below, to be minimum 26mm long and 4mm wide. This can be anywhere on the front face as e
2
unit can rotate in tube.
Connect cables to plugs, insert pin and socket connectors into the recess of the heat exchanger casing.
NOTE: The violet (purple) wire is always the signal (S1 or S2) connection
Cut out
4 mm
26
mm
Front face flush with GIB
