1 Notes
Technical Data
Power supply: 200-240 V AC 50/60 Hz
Remote control input: 0-10 V DC
Protection class: II
Protection type: IPX5
Air volume flow: OFF, 15-60/90* m³/h
Electrical power consumption: 1.8-6.2/14.5* W
Sound pressure level: 22-35/44* dB(A)
(with active humidity control „so to say“-stepless between 15 and 69/90* m³/h)
* depending on the control board
Every Silvento ec can be combined with a control board without a humidity sensor or with a humidity
sensor, each control board can be combined with one extension module.
This results in the following configuration options:
The Control board for the basement ventilation 5/EC-KE is optionally available and not listed here.
We will be pleased to inform you.
All units are equipped with class G2 filters and a filter change indicator.
Ventilation units of the "Silvento" series meet all requirements:
- of DIN 18017-3
- for low voltage (CE) according to EG guidelines (2006/95/EG; 2014/35/EU)
- for electromagnetic compatibility (CE) according to EC directives (2004/108/EC; 2014/30/EU)
Function/Control Board 5/EC-ZI 5/EC-FK 5/EC-ZI 90 5/-EC-FK 90
Adjustable volume flow base load
(DIP 1,2)
Adjustable volume flow
Demand ventilation (DIP 6,7)
Switch-on delay (-/45/120s) (/ / ) (/ / ) (/ / ) (/ / )
Follow-up time (-/15/30 min) (/ / ) (/ / ) (/ / ) (/ / )
Interval operation
(-/4h30min/2h15min)
(/ / ) (/ / ) (/ / ) (/ / )
Automatic (humidity/temperature) ( - / -) (/ ) ( - / -) (/ )
LED filter change indicator
Low voltage input 0-10 V
Data logging
Optional Radio Module FM-EO or
Motion Detector 5/BM
(/ ) (/ ) (/ ) (/ )
15/20/30/40/45/45/50/60 m³/h
15/20/30/40/45/45/50/60/90 m³/h
15/20/30/40/45/45/50/60 m³/h
15/20/30/40/45/45/50/60 m³/h
Installation in area 1 in bath and shower rooms in accordance with VDE 100 is permissible
Fan installation for use as extractor hood not permitted
Correct position and tight fit of the non-return valve if necessary (see Figure 5.7).
