Lust CDA32.003 - SFC for Rotational Drives (No Encoder)

CDA3000 Operation Manual
4-11
4 Commissioning
1
2
3
4
5
A
DE
EN
FR
IT
ES
FR
SFC commissioning, rotational
drive without encoder
Prerequisite:
• The motor specified for the application is connected.
• Control terminals wired according to
terminal assignment 2,
see page 3-14.
•A K
EYPAD KP200 or a PC with DRIVEMANAGER (version V2.3 or
higher) is connected. For operation see section 4.6 and 4.7.
Attention: Make sure the rotating drive in your machine cannot cause
any damage (e.g. overrunning its stop limit) during commis-
sioning.
Step Action Comment
1
Connect the KEYPAD or the PC to the
inverter module and switch on the
power to the inverter module.
After power-up the inverter module per-
forms a self-test (lasting approx. 1... 3
s).
2
Check that your drive can be run at
the rotating field frequency and with
the ramps as per the factory setting.
Rotating field frequency (FMAX) = 50Hz
with reference (R1) = 10 V
Acceleration ramp = 20 Hz/s
1)
Deceleration and stop ramp = 20 Hz/s
1)
If this is not possible, change the
parameters shown adjacent.
Subject area/Parameter
FMAX _30OL 303 -FMAX1
Acceleration
ramp _59DP 590 -ACCR1
Deceleration
ramp _59DP 592 -DECR1
Stop ramp _59DP 594 -STPR1
3
In subject area _15FC set
parameters
152-ASTER to ROT_1
ROT_1 = Control terminal
assignment
Analog speed input,
MOP function
4
Enter motor data (refer to motor
name plate) and confirm.
Rated power [kW] 154-MOPNM
Rated voltage [V] 155-MOVNM
Rated frequency [Hz] 156-MOFN
Rated speed [rpm] 157 -MOSNM
Rated current [A] 158-MOCNM
cos ϕ of motor 159-MOCOS
5
Close ENPO contact, set parameter
163-ENSC to START.
Automatic motor identification started,
lasts approx. 3-4 min., then automati-
cally jumps to STOP.
6
Select parameter 300-CFCON, set to
SFC, confirm.
Control mode:
Sensorless Flux Control (SFC) selected
7
Back-up the setting in subject area
_15FC with parameter 150-SAVE.
1) Factory setting from BG1
to BG5 (15 kW ) = 20 Hz/s, as
from BG6 (22 kW) to
BG8 = 5 Hz/s
Remember to
save the set-
ting.
• Call up subject area
_15FC
• Select parameter
150-SAVE
• Set parameter to
START and confirm
