* Press again, " Min " symbol appears on the left down
corner of the LCD and the Minimum value during
recording procedure will displayed on the LCD at the
same time.
* Press the MAX/MIN/. Button for around 3 seconds
to exit Data Record mode.
5. RS232 PC SERIAL INTERFACE
The instrument features an RS232 output via 3.5 mm
Terminal ( 3-15, Fig. 1).
The connector output is a 16 digit data stream which
can be utilized by user's specific application.
An RS232 lead with the following connection will
be required to link the instrument with the PC
serial input.
Meter PC
(3.5 mm jack plug) (9W 'D" Connector)
Center Pin..................................Pin 2
Ground/shield...............................
.
Pin 5
The 16 di
g
it data stream will be displayed in the
following format :
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
9
