2. SPECIFICATIONS
2-1 General Specifications
Circuit Custom one-chip of microprocessor LSI
circuit.
Display LCD size : 44 mm x 29 mm
dual function LCD display.
Measurement Humidity : %RH ( Relative Humidity )
Unit Temperature : or .℃℉
Dew point : or .℃℉
Response Time 5 to 30 seconds typically.
@ Reach the 85% reading value
Temperature Automatic temp. compensation for the
Compensation humidity function.
Data Hold Freeze the display reading.
Memory Recall Maximum & Minimum value.
Sampling Time Approx. 0.8 second.
Power off Auto shut off saves battery life.
Operating 0 to 50 .℃
Temperature
Operating Main instrument : Less than 85% R.H.
Humidity Probe : 0 to 95 %RH.
Power Supply 006P DC 9V battery
( Alkaline or Heavy duty type ).
Power Current Approx. DC 4.6 mA.
Weight 264 g/0.67 LB.
@ Battery is included.
Dimension
Main instrument :
135x60x33 mm, ( 5.3x2.4x1.3 inch ).
Humidity Sensor Probe :
197 mm ( 7.8 inch ) in length.
Accessories Instruction manual.....................
