Motorized shade with wireless radio frequency (RF) control.
Installation Guide—Please Read Before Installing
Serena® Remote-Controlled Shades
Insulating Honeycomb Shades
English
4
Lutron Electronics Co., Inc., 7200 Suter Road, Coopersburg, PA 18036-1299, U.S.A.
Printed in the U.S.A. 8/13 P/N 368-3194 Rev. B
2.3 Mount Shade in Brackets
Holding the shade in both hands, tilt the top of the shade slightly toward the window and hook
the front edge into the brackets behind the battery release tabs ( PUSH).Then rotate the back
of the headrail up and press the bottom of the headrail firmly until you hear it click into place.
IMPORTANT: Be certain no fabric cells are caught in the brackets.
bracket
hook
front
edge
end cap
omitted
for clarity
headrail - front
