4. MEASURING PROCEDURE
4-1 Preparation
1)Turn on the meter by pressing the " Power Button "
( 3-2, Fig. 1 ) momentarily.
* Pressing the " Power Button " ( 3-2, Fig. 1 )
continuously and > 2 seconds again will turn off the
meter.
2)Plug in the " Cable BNC Plug " ( 3-21, Fig. 1 )
to the " BNC Input Socket " ( 3-7, Fig. 1 ).
3)Plug in the " Mini plug of cable " ( 3-19, Fig. 2 )
to the " Input socket of vibration sensor " ( 3-18, Fig. 2 ).
Remark :
1. If the surface material of measuring article is not
the ferrous material, hold the vibration sensor by
hand & touch the sensor to the surface of the
measuring article,
* If the surface material of measuring article is the
ferrous material, connect " Vibration sensor " (
3-17, Fig. 2 ) with the " Magnetic base " ( 3-16, Fig.
2 ). Put the whole unit ( Vibration sensor &
Magnetic base ) to the surface of measuring article.
* Please do not use the finger or hand to touch the
the " Sensor cable " ( 3-20, Fig. 1 ).
