3.Press the " UNIT Button " ( 3-6, Fig. 1 ) once a while
will change the sampling time ( 1, 2, 5, 10, 30, 60,
600, 1800, 3600 seconds ). After the desired sampling
be selected, then press the " REC Button " ( 3-4, Fig. 1 )
to save.
4 Press the " ESC Button " ( 3-3, Fig. 1 ) once will return
the normal measuring screen.
Clear the memory ( clear the existing save data )
1.Power off the meter.
2.Use the two fingers to press the " HOLD Button " ( 3-3,
Fig, 1 ) and the " REC Button " ( 3-4, Fig. 1 ) at the same
time and not release those fingers, use another finger
to push the " POWER Button " ( 3-2, Fig, 1 ) once, then
until the display show the existing sampling time ( for
example 1, 2...), then release the two fingers at the
same time.
3.Press the " REC Button " ( 3-4, Fig. 1 ) continuously
at least 5 seconds, then display will show " 0 ".
Now the memory already be cleared.
Check the existing data that save into the memory
1.Power off the meter.
2.Use the two fingers to press the " HOLD Button " ( 3-3,
Fig, 1 ) and the " REC Button " ( 3-4, Fig. 1 ) at the same
time and not release those fingers, use another finger
to push the " POWER Button " ( 3-2, Fig, 1 ) once, then
until the display show the existing sampling time ( for
example 1, 2...), then release the two fingers at the
same time.
15
