Manual data logger
If the data sampling time already set to 0 second,
then the meter can be executed the manual data logger
function. The procedures that to set the data logger
sampling time, please refer page 14.
1.Press the " REC Button " ( 3-4, Fig. 1 ) once to
start the Data Record function and there will be a
" REC " symbol on the display.
2.Press the " LOGGER Button " ( 3-6, Fig. 1 ) once to start the
Manual Data Logger function. The upper display will
show " 0 " ( 0 second sampling time ) once a while then
revert to the normal display screen.
Press the " LOGGER Button " ( 3-6, Fig. 1 ) once again
will save one measuring data into the memory,
indicator will be flash per the sampling time, in the
same time, the beeper will sound a while.
3.If intend exit the Manual Data Logger function, just
pressing the " REC Button " ( 3-4, Fig. 1 ) at least
two seconds, then the " REC " indicator will be
disaapeared.
Change the data logger sampling time
1.Power off the meter.
2.Use the two fingers to press the " HOLD Button " ( 3-3,
Fig, 1 ) and the " REC Button " ( 3-4, Fig. 1 ) at the same
time and not release those fingers, use another finger
to push the " POWER Button " ( 3-2, Fig, 1 ) once, then
until the display show the existing sampling time ( for
example 1, 2...), then release the two fingers at the
same time.
14
