Temperature Manual 0 to 100 , be adjusted by℃
Compensation push button on front panel.
for pH Automatic With the optional temperature
measurement ( ATC ) probe ( TP-07 )
0 to 65 .℃
pH PH7, PH4, and PH10, 3 points calibration
Calibration ensure the best linearity and accuracy.
Optional * PH electrode..............
PE-03, PE-11, PE-01, PE06HD
probe and PE-04HD, PE-05T, PE-03K7
accessories * ATC ( automatic temperature
probe )....................................... TP-07
* pH 7 buffer solution..................... PH-07
* pH 4 buffer solution...................... PH-04
* ORP electrode.............................. ORP-14
Measurement Range Resolution Accuracy
PH 0 to 14 PH 0.01 PH ± (0.02 PH + 2 d)
mV 0 to 1999 mV 1 mV ± (0.5% + 2 d)
* PH accuracy is based on calibrated meter only.
B. Conductivity
Conductivity probeOptional, Carbon rod electrode for long life.
Function * Conductivity ( uS, mS )
* TDS ( Total Dissolved Solids, PPM )
* Temperature ( , )℃℉
Temperature Automatic from 0 to 60 (32 - 140 ),℃℉
Compensation with temperature compensation factor
variable between 0 to 5.0% per C.
Probe 0 to 60 .℃
Operating Temp.
Probe Dimension Round, 22 mm Dia. x 120 mm length.
Optional * Conductivity probe..........................CDPB-03
probe and * 1.413 mS Conductivity Standard
accessories Solution.........................................CD-14
6
