Setup
P
1. Plug one end of the provided power adapter into a wall outlet and the other
end into the back of the camera. See Fig. 3.
Note : Use the adapter labeled OUTPUT: 6V DC with the camera.
2. Press the POWER button and keep it around 3 seconds to turn on the
camera. The LED on the camera will light up (green light). See Fig. 3.
Note : Press the POWER button and keep it around 3 seconds to turn off
the camera.
Fine Tuning
Place the camera in a convenient location, point the lens toward the observation
area and adjust the angle by rotating the lens head. See Fig. 4.
Night Vision
The camera has eight high-intensity LEDs for picking up clear images in the
dark. When the light sensor detects low ambient light levels, the LEDs will be
automatically activated.
Room Temperature Measurement
Temperature sensor can measure room temperature on camera side and the room
temperature indicator will be displayed on the screen of the monitor unit.
Camera Setup
ower Supply - Using AC Power
1
1.1
1.2
1.3
1.4
Power Supply
current.
Loading the Battery
1. Open the battery compartment cover on the rear of the monitor. See Fig. 5.
2. Insert the battery with the metal facing the battery compartment. See Fig. 5.
3. Close the battery compartment cover, and make sure it is locked securely.
4. Press the POWER button and keep it around 3 seconds to turn the
monitor on. See Fig. 5.
Note 1: When power is sufficient, the "Power/Charging" LED will light up
(green light); When battery is low, the red LED light will start blinking.
Note 2: Press the POWER button and keep it around 3 seconds to turn off the
monitor.
Monitor Setup
The monitor uses 3.7V 1100mAh (Li-ion) battery or the household AC power
2.1
2
