Quick Install Guide
ABR-4400
a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450
LUX-QIG-ABR-4400 117141122
4
LED Indicators
Indicator Description Function
POWER Power LED ON indicates the ABR-4400 has power.
SYSTEM System
Status LED
FLASHING indicates the ABR-4400 is functioning
correctly.
ON indicates the ABR-4400 is booting.
OFF indicates the system is not functioning correctly.
USB USB Connection
Status
ON indicates a USB device is connected and configured
WAN/LAN
Front
WAN and LAN
Status LED
BLUE/GREEN TOP ROW ON
indicates there is a 10/100 Mbps device connected
BLUE/GREEN BOTTOM ROW ON
indicates there is a 1000 Mbps device connected
FLASHING BLUE/GREEN
indicates data packets are being transferred.
WAN/LAN
Rear
WAN and LAN
Status LED
YELLOW ON
indicates there is a 10/100 Mbps device connected
GREEN ON
indicates there is a 1000 Mbps device connected
FLASHING YELLOW or GREEN
indicates data packets are being transferred.
WAN Ports: (1 dedicated, 3 shared) RJ-45 Ethernet Ports for connecting up to
4 independent internet connections
LAN Ports: (1 dedicated, 3 shared) RJ-45 Ethernet Ports for connecting to the
local network
USB Ports: 1 USB 2.0 ports for connecting USB based printers and hard drives.
NOTE: It is recommended that a Luxul switch be used in conjunction
with the ABR-4400 to increase number of local ports available.
PREPARING FOR INSTALLATION
System Requirements
Ethernet Cables to connect the ABR-4400 to Ethernet enabled devices
USB Cables to connect the ABR-4400 to USB 2.0 enabled devices
