Specifications
Electrical
Note: Battery packs may leak up to 1mA current through the battery contacts when left in an unpowered battery charger
charging pocket.
Parameter Minimum Maximum Note
Power Supply Input Voltage (V
AC-IN
) 100 VAC 240VAC Auto-switching
Power Supply Input Frequency (freq) 47Hz 63Hz
Temperature
Function Minimum Maximum Note
Operating
0°C
(32°F)
+40°C
(104°F)
Battery Pack
Charging
0°C
(32°F)
+40°C
(104°F)
Battery packs will not begin charging when their internal temperature is
outside this range.
Storage
-20°C (-
4°F)
+70°C
(160°F)
Unit is off.
Dimensions
Weight 1.75 lbs / .79 kg
Length 12.25” / 31.1 cm
Width 5.25” / 13.3 cm
Height 1.5” / 4 cm
Plug Type IEC320 (3 prong, grounded)
Li-Ion 7.4V 2.2Ah battery with a 500 charge/discharge life cycle
Battery Charger Revision History
Revision / Date Location / Change
A / Oct 2010 Initial Release
E-EQ-MX7TCHGROG-A [ 19 ] MX7 Tecton™ Battery Charger User Guide
