Lycomin 0-360 - Page 36

TEXTRON
LYCOMING
OPERATOR'S
MANUAL
SECTION
2
*Accessory
Drive
0-360
and
ASSOCIATED
MODELS
Drive
Ratio
**Direction
of Rotation
Starter
Generator
Generator
Alternatort
Tachometer
Magneto
Vacuum
Pump
Propeller
Governor
(Rear
Mounted)
Propeller
Governor
(Front
Mounted)
Fuel
Pump
AN20010
Fuel
Pump
AN20003***
Fuel
Pump
- Plunger
operated
Dual
Drives
Vacuum
-
Hyd.
pump
Vacuum
- Prop.
Gov.
16.556:1
1.910:1
2.500:1
3.20:1
0.500:1
1.000:1
1.300:1
0.866:1
0.895:1
0.866:1
1.000:1
0.500:1
1.300:1
1.300:1
Counter-Clockwise
Clockwise
Clockwise
Clockwise
Clockwise
Clockwise
Counter-Clockwise
Clockwise
Clockwise
Counter-Clockwise
Counter-Clockwise
Counter-Clockwise
Counter-Clockwise
NOTE
Engines
with
letter
"L"
in
prefix
will
have
opposite
rotation
to the
above.
*
- When
applicable
** -
Viewed
facing
drive
pad
*** -
TIO-360-C1A6D,
HIO-360-E,
-F have
clockwise
fuel
pump
drive
t
- HIO-360-D1A
-
Alternator
drive
is
2.50:1
2-8
