Ionic Series User Manual
Lynx Pro Audio S.L 10www.lynxproaudio.com
• CONNECTION EXAMPLE (mono channel): Two Ionic-100 + one Ionic-18S PRESET 1
CONNECTORS AND CONNECTIONS
ACOUSTIC CENTRE
Connect to
power input
Speakon +1/-1
Connect to
power output
Speakon +1/-1
Speakon
+1/-1
Speakon
+1/-1
Connect to
power input
Cabinet placed
upside down
