BACK PANEL
The Ionic-50 columns are powered from the active subwoofers Ionic-12S. In the following drawing you can see
the back panel of the Ionic-12S, which includes the power amplications and the digital signal control board.
From the sub unit back panel you can also select various preset congurations using the LCD display and
digital control buttons. You can see how to congure the cabinet DSP options on page 13.
* Available when the user has requested the cabinets to be supplied with the Ethernet Module kit.
USB connection
LCD display &
digital control
Signal Input
Signal Output
Output power
speakon +1/-1
Main input Main link
* Ethernet
OPTIONAL
