Ionic Series User Manual
Lynx Pro Audio S.L 6www.lynxproaudio.com
• Ionic-12S
The Ionic-12S is a powered subwoofer enclosure. It uses 1 x 12” (3” voice coil) neodymium transducers
offering an ultra compact subwoofer enclosure with 127dB SPL. The power module (Class D with
switching power supply) includes a Digital Signal Processor which offers different presets to cover a
wide range of sound applications complementing the column speakers.
• Technical Data:
Components:
• LF: 1 x 12” speaker with 3” voice coil
Frequency range: 40 Hz – 250 Hz (-10dB)
Frequency response: 46 Hz – 250 Hz (± 3dB)
Max SPL / Peak: 127 dB
Coverage angle: Omnidirectional
Power amplier: 1400W Class D with switching power supply & PFC
LF amplier:1 x 700W
Speaker output amplier: 1 x 700 W @ 8 Ω
Processing: 48 KHz / 56 bit double precision DSP
Control: User control interface with LCD
Control connections: Ethernet (OCS) optional / USB (DSP programming)
AC Power: 85 – 270V. 50/60 Hz with PFC
AC Connectors: 16A Neutrik powerCon TRUE1 with looping output
Finish: Polyurea coating, high grade resistant paint
Material: 15 mm Premium birch plywood
Dimensions: 407 x 440 x 520 mm (H x W x D)
Weight: 23 kg (50.6 lbs)
• Ionic-12S measurements
