Lynx L30 Series Care & Use

5
Cutout Dimensions for 2008 Built-ins
Professional Grills and ProSear Pod
Complementary Products
Model A B C D E F G H
L27 - 26 22 - - - - -
L30 - 29 24 1/2 - - - - -
L36 - 35 22 - - - - -
L42 - 41 24 1/2 - - - - -
L54 - 53 24 1/2 - - - - -
Model A B C D E F G H
Access Doors
LDR21-1 - - - 19 1/4 - - - -
LDR27-1 - - - 25 1/4 - - - -
LDR30-1 - - - 28 1/4 - - - -
LDR36-2 - - - 34 1/4 - - - -
LDR42-1 - - - 40 1/4 - - - -
Side Burners and ProSear Grill Extender
LSB1 12 1/8 - 24 1/2 - - - - -
LSB2 12 1/8 - 24 1/2 - - - - -
LSB2PC 24 1/4 - 24 1/2 - - - - -
LPSGE 12 1/8 - 24 1/2 - - - - -
Utility Drawers
LUDE - - 24 - 12 1/8 19 1/4 - -
LUDXL - - 24 1/4 - 17
1/4 18 9/16 - -
Warming Drawers
L30WD - - 20 1/2 - - - 28 1/2 10
L42CC - - 24 1/2 - - - 40 1/4 19 3/8
CocktailPro
CS30 - - 22 3/4 - - - - -
Specifications are subject to change without notice.
*CocktailPro should have an
open bottom for plumbing
and drain access.
Model a b c d e f
LIJ27 33 5 24 4 1/2 3 11 5/8
LIJ30 36 5 26 1/2 4 1/2 3 11 5/8
LIJ36 42 5 24 4 1/2 3 11 5/8
LIJ42 48 5 26 1/2 4 1/2 3 11 5/8
LIJ54 60 5 26 1/2 4 1/2 3 11 5/8
With Insulated Jacket Installed
Note: Insulated jacket required for all grills installed
into a combustible enclosure. See detail below.
Insulated
Jacket
a
f
e
c
d
b
2" 0 or 2" square holes
for manifold connection
(rear or bottom access)
12" min.
Grill
CocktailPro*
Warming Drawer/
Convenience Center
Utility
Drawer
Side
Burner
Access
Doors
19"
A
B
D
E
G
F
H
29"
2 1/4"
4 1/2"
min.
3 1/2"
1 1/8"
min.
1 1/8" min. for model LUDE
3 1/2" min. for model LUDXL
2 1/2" min. for model LDR
3 1/4" min.
2"
10 7/8"
36 3/8"
min.
C
10 1/8" for L36 models
Dim C to cabinet face
5/8" for Grills
9/16" for Complementary Products
Depth equals
countertop
overhang
Counter top Notch Detail
