38
|
SEDONA CARE & USE/INSTALLATION
BTU OUTPUTS & MAXIMUM RUNS
MODEL-SPECIFIC BTU OUTPUTS
MODEL TUBE BURNER ROTISSERIE PROSEAR™ TOTAL INPUT
L500PS 1 @ 23,000 Btu/Hr N/A 1 @ 23,000 Btu/Hr 46,000 Btu/Hr
L500PSR 1 @ 23,000 Btu/Hr 1 @ 12,500 Btu/Hr 1 @ 23,000 Btu/Hr 58,500 Btu/Hr
L600PS 2 @ 23,000 Btu/Hr N/A 1 @ 23,000 Btu/Hr 69,000 Btu/Hr
L600PSR 2 @ 23,000 Btu/Hr 1 @ 14,000 Btu/Hr 1 @ 23,000 Btu/Hr 83,000 Btu/Hr
L700PS 2 @ 23,000 Btu/Hr N/A 1 @ 23,000 Btu/Hr 69,000 Btu/Hr
L700PSR 2 @ 23,000 Btu/Hr 1 @ 16,000 Btu/Hr 1 @ 23,000 Btu/Hr 85,000 Btu/Hr
MAXIMUM RUNS FOR ALL
APPLIANCES ON SUPPLY LINE
Run Length
3/4” Pipe (in feet)
Max BTU for all
Appliances on line
10 360,000
20 245,000
30 198,000
40 169,000
50 150,000
60 135.000
70 123,000
80 115,000
NOTE: IF A 1/2 INCH LINE IS USED
WITH NATURAL GAS IT SHOULD BE
NO LONGER THAN 12 FEET.
