User Guide 11Fast Track Ultra 8R
The Control Panel features eight tabs across the top of the screen. These tabs provide access to specific features of
Fast Track Ultra 8R. These tabs are described in detail below.
Monitor Tabs
The four Monitor tabs are similar in layout and in operation and allow you to create four separate monitor mixes from the
eight hardware inputs and eight software returns from your audio application.
Each tab controls a separate pair of outputs:
Monitor 1/2
→
Hardware Outputs 1/2 (and Headphone Out 1)
Monitor 3/4
→
Hardware Outputs 3/4 (and Headphone Out 2)
Monitor 5/6
→
Hardware Outputs 5/6
Monitor 7/8
→
Hardware Outputs 7/8 (and S/PDIF output)
The Monitor tabs’ outputs correspond to Fast Track Ultra 8R’s hardware outputs. Monitor outputs 7/8 are duplicated at
the analog Line Outputs
19
and the S/PDIF digital output
18
.

M-Audio Fast Track Ultra 8R Specifications

General

Audio Interface Type	USB
Number of Mic Preamps	8
Analog Inputs	8 x XLR/TRS Combo
Analog Outputs	8 x TRS
MIDI I/O	In/Out
Phantom Power	Yes
Headphone Outputs	2
Sample Rate	96 kHz
Bit Depth	24-bit
Digital Inputs	1 x S/PDIF Coaxial
Digital Outputs	1 x S/PDIF Coaxial
Software Included	Pro Tools SE
