M-Audio OXYGEN PRO MINI User Manual

17
SHIFT Button
When this button is pressed and held it will enable you to select SHIFT modifier functions of
the keyboard.
Back Button
When in any of the keyboard’s available editing modes, this button will send a message to go
back to a previous menu. When not in any of the edit modes, this button will send a separate
MIDI, Mackie or Mackie/HUI message in DAW mode. When in PRESET mode, this button will
send a separate user editable MIDI message when preset 1-14 is selected.
When SHIFT is pressed and held with this button it will delete the currently selected letter
when saving a User Preset Name, or User DAW Name.
Encoder and Encoder Button
When in any of the keyboard’s available editing modes this Encoder is used for scrolling
through selections when turned left and right and will enter when pressed. When in DAW
Mode this Encoder will send separate Up/Down or Left/Right messages (depending on the
DAW), and Enter messages. In Preset mode this Encoder will either send the same message
as the DAW Encoder assignment or send Program or CC messages.
When NOTE REPEAT is active the Encoder will be used for selecting NOTE REPEAT and
ARP time division settings.
Mode Button
The Mode button’s LED will be lit to show that the Fader Buttons secondary function is active.
The secondary function is dependent on what mode the keyboard is in, DAW or Preset, and
what “Button” selection is active in the Global functions, Record, Solo, Mute, or Select. In
Preset and DAW mode, the fader buttons silkscreened options will always be available for
selection. In DAW mode, the fader buttons silkscreened options will be available for selection,
as well as track Record (Record arm), Select, Mute, and Solo. In Preset mode, the fader
buttons silkscreened options will be available for selection, as well as user editable MIDI
messages.
DAW Mode
• Off/No LED: Fader Buttons will activate the following options:
o ARP On/Off, ARP Edit Enter/Exit
o ARP Latch On/Off
o Smart Chord On/Off, Chord Edit Enter/Exit
o Smart Scale On/Off, Scales Edit Enter/Exit
• Rec/Mode LED lit: Fader Buttons will activate Record Arm MIDI, Mackie, or Mackie/HUI
messages for the associated button’s current channel in your DAW.
• Select/Mode LED lit: Fader Buttons will activate Track Select MIDI, Mackie, or
Mackie/HUI messages for the associated button’s current channel in your DAW.
• Mute/Mode LED lit: Fader Buttons will activate Mute MIDI, Mackie, or Mackie/HUI
messages for the associated button’s current channel in your DAW.
• Solo/Mode LED lit: Fader Buttons will activate Solo MIDI, Mackie, or Mackie/HUI
messages for the associated button’s current channel in your DAW.

M-Audio OXYGEN PRO MINI Specifications

General

Control type	Buttons, Rotary, Slider
Number of pads	8
MIDI-keyboard number of keys	32 keys
Product color	Black
Octave adjustment	Yes
Display type	OLED
Power source type	USB

Weight and Dimensions

Depth	190 mm
Width	401 mm
Height	60 mm
Weight	1200 g
