M-Audio OXYGEN PRO MINI User Manual

8
Features
Top Panel
Keybed/Octave/Wheels
Note: Text below accompanying keyboard controls indicates secondary functions that
can be accessed by pressing SHIFT while using the control.
1. Keybed: This velocity-sensitive keybed is the primary method of sending Note
On/Off MIDI data.
Hold Shift and press keys C2–Bb3 to edit Chord Mode settings. See Basic
Concepts to learn more about this feature.
2. OCTAVE: Press these buttons to adjust the pitch range of the keys up or down
one octave. Hold Shift and press these buttons to adjust the pitch range of the
keys up or down one semitone. The keyboard can be raised up to four octaves
or lowered down to three octaves from its default octave range and a total of
twelve semitones from its default transposition.
To reset Oxygen Pro Mini to its default octave range and transposition (F2–C5
on the keybed), press the Octave - and Octave + Buttons simultaneously.
3. PITCH: Roll this wheel up and down from the center position to bend the pitch
of the keyboard while playing. The default range of the pitch-bend will vary
between software synths. The wheel is spring mounted and will return to the
center position when released.
4. MOD: Move this wheel to send continuous controller data—MIDI CC #01
(modulation), by default.
1
2
3
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
22
23
24
20

M-Audio OXYGEN PRO MINI Specifications

General

Control type	Buttons, Rotary, Slider
Number of pads	8
MIDI-keyboard number of keys	32 keys
Product color	Black
Octave adjustment	Yes
Display type	OLED
Power source type	USB

Weight and Dimensions

Depth	190 mm
Width	401 mm
Height	60 mm
Weight	1200 g
