Data Sheet B.Beat PRO16Data Sheet B.Beat PRO16 Data Sheet B.Beat PRO16Data Sheet B.Beat PRO16
Internal Audio File Format
MIDI port
Video
External power supply unit
USB ports
Internal Video Format
Pedal
Power supply
Compatible image formats
Video resolution for lyrics
Input Input
Output
Jack Headphone Output
Internal memory
Network Interface
Digital processing Internal audio
inputs
Display
Digital processing
Internal audio outputs
PCM (uncompressed) 48 kHz 24 bit
MIDI OUT DIN 5-pole standard
MIDI IN via USB-MIDI cable (optional)
2x Video Type A output
Maximum resolution 1920x1080 with video
AC/DC Adapter Mod. 13/90288-00 INPUT 100-
240VAC Freq 50-60Hz OUTPUT 12VDC - 2A
2x USB 2.0 Hi-Speed Type A per Memory Stick,
Wireless USB interface. Max. total current
delivered for the two ports: 500mA
H-264 HD / Full HD (1280 x 720 / 1920 x 1080)
Switch Pedal N/O or N/C, Jack 6.35mm
12VDC, 2A, max. consumption 19W
JPG, PNG
1920 x 1080
- 12 Line Jack 6.35 mm mono inputs, unbalanced
- Impedance 10 kΩ
- Range 18dBu, 6 Vrms
- Typical THD+N -93 dB
- Typical SNR 107 dB
- 12 Line Jack 6.35 mm mono inputs, unbalanced
- Impedance 10 kΩ
- Range 18dBu, 6 Vrms
- Typical THD+N -93 dB
- Typical SNR 107 dB
12 channels A/D 24 Bit Sigma/Delta 48 kHz.
Typical S/N ratio 107 dB
- 16 Audio outputs Jack 6.35 mm mono, balanced
- Range 10dBu, 2.5 Vrms
- Range 20dBu, 5 Vrms (balanced)
- Typical THD+N -94 dB
- Typical SNR 112 dB
- Stereo Jack 6.35 mm output
- Typical SNR 105 dB
- Range 6dBu, 1.5 Vrms
128GB, 1TB depending on version
RJ45 10/100/1000 Mbps Ethernet socket
2.4" OLED, 128x64, Monochrome
16 D/A channels 24 Bit Sigma/Delta 48 kHz.
Typical S/N ratio 112 dB
MP4,MOV
Compatible Audio Formats
during import
(which will be converted
into the internal format)
Compatible Video Formats
during import
WAV 44.1 kHz, 48 kHz, 96 kHz 16/24 bit
MP3 fixed bit rate [64 - 320] kbps
MP3 VBR
OGG fixed bit rate [64 - 320] kbps
AAC
STEMS
