MODEL: MSP5
Operation at abnormally low input: Extend, retract or stop;
field selectable with DIP switches (factory set to “extend”)
Detectable input drop level: -16 ±2.5 %
Electrical connection
•No terminal box
Wiring conduit: G 1/2 female; cable connector with 1 meter
wire (0.5 mm
2
) provided
•Terminal box
Wiring conduit: G 1/2 female (two)
Terminal screws: M3 pillar terminal
(Sequential control signal suffix code B)
M3 chromated steel
(other terminal box types)
(torque 0.5 N·m)
Housing material: Diecast aluminium
Drive: Stepping motor
Position detection: Potentiometer
Deadband: 0.1 – 4.5 % adjustable (factory set to 1.5 %)
Restarting timer: 0 – 10 sec. adjustable
(factory set to 1.5 sec.)
Isolation: AC power to signal
Zero adjustment: 0 – 25 %
Span adjustment: 50 - 100 %
Protective functions: Overload protection
Power indicator: Green LED turns on with power supplied.
Input indicator: Green LED turns on with normal input
Status indicator LED: Red light blinks in 2 sec. intervals in
normal operations; blinks in 0.5 sec. intervals when a
foreign object is detected mechanically caught inside.
Manual operation: Not available
INPUT SPECIFICATIONS
DC Current: Input resistor incorporated (250 Ω)
DC Voltage: 1 – 5 V DC or specific range within 0 – 5 V DC,
minimum span 1 V
(For a current input, convert the current to a voltage with
250 Ω)
Input resistance: Approx. 1 MΩ
Forced open/close signal: Dry contact inputs to command
to retract and extend
Rating: 5 V DC @ 2.5 mA
OUTPUT SPECIFICATIONS
Operation Time & Thrust (at rated power voltage)
(Model: Operation Time: Thrust)
MSP5-x3: 5 sec. / 10 mm: 150 N (33.5 lbs)
MSP5-x4: 9 sec. / 10 mm: 300 N (67 lbs)
MSP5-x7: 18 sec. / 10 mm: 700 N (157 lbs)
Position Output: 1 – 5 V DC (not isolated)
With “direct” action, 5 – 1 V DC position output is provided
proportionally to 4 – 20 mA DC (1 – 5 V DC) input.
Load resistance: ≥ 5 kΩ
Full-open / -closed signals: Limit switch contact
Rating: 125 V AC @ 0.75 A (cos ø = 1)
30 V DC @ 0.6 A (resistive load)
Mechanical life: 3 × 10
7
cycles
Maximum operation frequency: 60 cycles/min.
INSTALLATION
Power Consumption
AC power input: Approx. 25 VA
DC power input: Approx. 0.6 A
Operating temperature: -5 to +55°C (23 to 131°F)
Operating humidity: 30 to 85 %RH (non-condensing)
Vibration: 0.5 G max.
Mounting position: All directions
Do not mount the actuator with its output stem or cable
connector on the upside if the actuator is to be exposed to
dripping water.
Weight
DC powered: 1.2 kg (2.65 lbs)
AC powered: 1.4 kg (3.09 lbs)
Add 0.7 kg (1.54 lbs) for the terminal box.
PERFORMANCE
Resolution: 1/1000 or 0.015 mm, whichever is greater, with
0.1 % deadband setting
Insulation resistance
AC powered: ≥ 100 MΩ with 500 V DC
(signal or metallic housing to power)
≥ 100 MΩ with 100 V DC
(signal to metallic housing)
DC powered: ≥ 100 MΩ with 100 V DC
(signal or power to metallic housing)
Dielectric strength
AC powered: 1500 V AC @ 1 minute
(signal or metallic housing to power)
100 V AC @ 1 minute
(signal to metallic housing)
DC powered: 100 V AC @ 1 minute
(signal or power to metallic housing)
STANDARDS & APPROVALS
CE conformity:
EMC Directive (2004/108/EC)
EMI EN 61000-6-4: 2007
EMS EN 61000-6-2: 2005
Low Voltage Directive (2006/95/EC)
EN 61010-1: 2001
Measurement Category II
Pollution Degree 2
Full-open/-closed signal to other, power or metallic
