General
Channels 40
Modulation FM/AM
Frequency Range 26.965 - 27.405 MHz
Frequency Tolerance +/-200Hz
Input Voltage 13.2V DC
Dimensions 125(L) x 38(H) x 126.5(D) mm
Weight Approx. 0.6 kg
Antenna Impedance 50Ω
Transmitter
Maximum Output Power 4W
Transmission Interference <4nW
Audio Response 300Hz to 3KHz
Emitted Power in the Adj. Channel <20µW
Microphone Sensitivity 7mW
Drain <1.8A (with modulation)
Modulated Signal Distortion 3%
Receiver
Max. Sensitivity at 20dB Sinad <1µV
Frequency Image Rejection Rate >60dB
Adjacent Channel Selectivity >60dB
Intermediate Frequency Rej. Rate >60dB
Drain <700mA
Squelch Sensitivity Min. <0.5µV; Max. =1mV
Frequency Response 300Hz to 3KHz
Maximum Audio Power >2W
LEGEND II PLUS
All stated specifi cations are subject to change without notice or obligation.
SECTION 6
SPECIFICATIONS
All stated specifi cations are subject to change without notice or obligation.
16
