❿SQUELCH KNOB
Adjusts the level of the squelch
manually or turns to automatic
control squelch mode (ASQ).
⓫RF GAIN KNOB
Adjusts the level of the signal
reception.
⓬CHANNEL SELECTOR
Select channel to be use. This
selector disable once the
emergency channel selected.
⓭3.5MM SOCKET FOR EXTERNAL
LOUD SPEAKER
⓮ANTENNA CONNECTOR
⓯POWER SUPPLY CABLE
❶AM/FM SELECT SWITCH
Switch modulation mode to
AM or FM.
❷ FUNCTION SETTING MODE
SWITCH
Switch function setting mode
ON or OFF.
❸ HI-CUT SELECT SWITCH
Switch eliminates high
frequency interferences ON
or OFF.
❹DW (DUAL CHANNEL WATCH)
SELECT SWITCH
Switch to DW mode ON or OFF.
❺TX LED
Indicates when the radio is
transmitting.
❻ S/RF METER
Shows the strength of the
received signal or the RF output.
❼CHANNEL INDICATOR
Displays the channel in use.
❽ MICROPHONE SOCKET
Connects to the microphone.
❾VOLUME CONTROL
Power ON/OFF the radio and
adjusts the volume.
SECTION 2
CONTROLS AND PANEL
6
