M2I XTOP07TW - Page 9

9
[Table1. Outer Dimension]
Model
FRONT
SIDE
REAR
F1
F2
S1
S2
S3
R1
R2
XTOP10TV-E
270
212
58
199.9
49.8
257.9
199.9
XTOP10TV/TS-S
305
239
58
226.4
51
292.4
226.4
XTOP12TS-S
317
257
58
244.3
51
303.8
244.3
XTOP15TX-S
366
296.5
58
283.5
51
352.8
283.8
Front Part Names and Specifications
No.
Title
Feature
LCD
Model
10TV-S
10TV-E
10TS
12TS-S
15TX-S
TYPE
TFT 65,536 Color LCD
1
Brightness
380cd/㎡
350cd/㎡
400cd/㎡
380cd/㎡
350cd/㎡
Screen Size
26cm
10.4inch
31cm
12.1inch
38cm
15inch
Resolution
640X480
800X600
1024X768
2
Touch
Panel
Touch Type
Analog
3
Front Sheet
Front Vinyl Cover Sheet for Damp Proof and Dust Proof
4
Status LED
Status of Power, Communication and CPU
5
USB Port
USB Download Port
Rear Part Names and Specifications
No.
Title
No.
of Pin
Feature
1
Rubber Packing
Shock Absorber for Panel Mounting
2
Switch
Power Switch
3
Power Input Terminal
3
Input voltage typical 24VDC
4
USB Connector
USB Connector for USB Storage
5
ETHERNET Connector
Download or ETHERNET Communication
6
RS-232C Connector
9
COM2 RS-232CSerial Comm. for Comm. with PLC
7
RS-422 Connector
9
COM2 RS-422 Serial Comm. for Comm. with PLC
8
PS/2 Connector
6
COM1 Serial Comm. for Download/Upload
9
CF-Card Connector
CF-Card Memory Option Connector
10
FieldBus Connector
Extension-Card Connector for Fieldbus or CC Link
Note: XTOP10TV-E have options for above item No. 5,9,10. Please check the details of each model’s specifications.
