Front
panel
Indoor Unit
Air inlet
Display
Emergency panel
Vertical adjustment louver
Horizontal
adjustment
louver
Outdoor Unit
Remote control
Air inlet
Air outlet
Air filter
Drain hose
Note: Condensation water drains during
the COOLING and DRY modes.
Pipes and power
connection cord
Air
outlet
parts of the system
Note: The illustrations shown in this manual were generated based
on the external appearance of a standard model, consequently the
appearance of your model could differ from that of the illustrations.
