mabe MSC504SORBS0 - Control Panel

50
control panel
Freezer compartment tem-
perature
QUICK REF. icon
QUICK FRZ. icon
Fresh food compartment
temperature
VACATION icon
display
8
7
6
3
2
1
4
5
WATER FILTER icon
ICE OFF icon
Ice cubes icon
Crushed ice icon
Cold water icon
LOCK/UNLOCK icon
9
10
buttons
Freezer compartment tem-
perature adjustment.
Fresh food compartment
temperature adjustment.
MODE selection.
OFF/ON ICE button.
ICE/COLD WATER/FILTER DIS-
PENSER button.
LOCK/UNLOCK control.
A
B
C
D
E
F
model SxS 504
11
