Mac Afric BV20BL - Machine Illustration - Oil and Gearbox Components; Oil Sight Glass and Drain Plug (Figure 8); Gearbox Access and Safety Switch (Figure 9 & 10)

11
Fig 8 Fig 9
Headstock cover plate
Oil sight glass
Oil drain plug Door for change gear box
Fig 10
Machine Illustration and key parts description
Door micro-switch
