4
Model: BV20-BL
Motor 230V a.c. 550W
Maximum swing over the bed 110mm
Maximum distance between centers 350mm
Spindle Speeds Forward and Backward 170,312,450,736,1354,1950
Reversing Method Electrical
Clear Bore in Headstock Mandrel 20mm
Possible metric thread pitches 17
Possible imperial tip’s 17
Number of possible feed speeds 5
Maximum longitudinal travel of compound rest 70mm
Maximum traverse travel of compound rest 115mm
Maximum turning angle of compound rest + or – 45 degree
Maximum extension of tailstock barrel 50mm
Leadscrew Gearbox ratio 6:1
Weight 140Kg
Overall size(Lathe only) 1050 x 615 x 560mm
Main Axis This is the axis established through the spindle of the headstock. It is
horizontal to and parallel with the lathe bed along its length.
Work Axis This is the axis established by the work piece, it is horizontal to but not
necessarily parallel with, the lathe bed, along its length.
Traverse
Axis
This is the axis described by the traverse slide when it is being moved
independently of the saddle. It is perpendicular to the main axis in the
horizontal plane.
Compound
Axis
This is the axis described by the compound slide when it is being operated
independently of the traverse slide and the saddle.
Machine Specifications
Definitions
