8
Fig 1
Fig 2
Tailstock barrel Clamping lever Chuck assembly
Machine Illustration and key parts description
Chuck safety cover
Chuck
Headstock
Tool Post
Tailstock
Rack Leadscrew Protection cover
Compound slide
Saddle
